What is the minimum load requirement for this clamp? I would be using this clamp to habitually lift 3/8" thick steel plate that weighs between 375 and 400 lbs in a 36" x 98" sheet. Since it is advisable for safety and longevity of the clamp to lift as close to the max capacity as possible, if this clamp will not work, do you have another model # that will?
AMH 1 Ton Vertical Plate Lifting Clamp - #PCUA010
Status:
Open Mar 02, 2021 - 11:51 AM
1answer
Answer
Mar 06, 2021 - 10:49 AM
A minimum weight equal to 10% of the WLL is required to ensure grip. Provided you're lifting in the 300-400 lbs range, and using the clamp as directed, you should be fine. All clamps have wear parts that, over time, will need replacing
View More Product Details
AMH 1 Ton Vertical Plate Lifting Clamp - #PCUA010
" AMH PCUA Vertical Plate Clamps – Secure Lifting for Steel Plates \n The AMH PCUA Vertical Plate Clamps are engineered for vertical lifting and handling of steel plates with strength, reliability, and operator-controlled engagement. Constructed with a forged steel body and a spring-loaded cam,...
